Pet Bottle Pre Position Shrink Sleeve Labeling Machine
Detailed Product Description

Input Power::4.5KWInput Voltage::3Φ380V/220VAC
Speed:400 Bs/minSize Of Host Machine:3000(L) X 1000(W) X 2500(H)

Automatic shrink sleeve label machine for PET bottle

Feature of pvc shrink sleeve applicator label for bottles cap labeling machine :

1. The sleeve label is unwound evenly from the reel via feed roller and conveyed to the cutting unit via the sleeve supply unit.

2. There, the sleeve is opened by pulling it over a mandrel, a servomoter-controlled cutter cuts the sleeves exactly to the set length.

3. After that, the applicator fork pulls the sleeves over the container.

4. Depending on the container shape and the sleeve size, an optional positioning brush moves the sleeve to the desired position. As a result, each sleeve is in perfect position and cannot slip.

5. Optional hot-air nozzles shrink and pre-position the sleeves. After that, the sleeves are shaped perfectly around the container contour in a steam or hot-air tunnel.

Input Power:4.5KW
Input Voltage:3Φ380V/220VAC
Speed400 bs/min
Size of host machine”3000(L) X 1000(W) X 2500(H)
Applicable Diameter of Bottle BodyΦ28mm-Φ125mm
Applicable Length of Label:30mm-250mm
Applicable Thickness of label0.03mm-0.13mm
Applicable Internal Diameter of Paper Tube:5”-10”(Free adjustment)


1. Offer you professional labeling sulution according to your specific labeling requirements.

2. Supply you high quality labeling machine after placing order.

3. Try to make the delivery time as short to meet your needs.

4. Provide you lifelong free technical support after you receiving our machine.

PET bottle pre position shrink sleeve labeling machine Automatic

Tag: shrink sleeve applicator machine, shrink sleeve label applicator
