Fully Automatic Top Labeling Machine For Plastic Empty Envelope Bag Labeling

Detailed Product Description

Automatic Grade:	Automatic	Label Type:	Sticker / Self Adhesvie
Driven Type:	Electric	Machine Material:	Aluminum Adozing And 304 Stainless Steel
Labeling Accuracy:	±1mm	Label Max Width:	130mm
Suitable Range:	Label On Top

Full Automatic Top Labeling MachineFor Plastic Empty Envelope Bag Labeling

Application

1,Top label on plastic empty envelope bag labeling ,mask,unspreading carton labeling

2,Speed 50-200pcs/min

3,Changing different size products,no need to change the part ,only need to adjust the machine

4, Labeling accuracy is ±1mm.

5, The machine can save 20 sets parameters,the parameters can save for ever ,when you want to do it you can call it out.

Technical Parameters

Production speed	1-50m/min
Labeling accuracy	±1mm
Label max width	130mm
Label inner diameter	76.2mm
Label outer diameter	330mm
Outline size	L2000×W700×1400mm
Weight	180KG
Using power	220V 50HZ 1500W
Bottle diameter	10-300mm

Product Characteristic

1 , The top surface labeling machine available to label on top,the perfect design and the advanced controlling and checking system guarantee it is labeled speedily and precisely.

2 , The famous high precise serve motor drives the labeling head and controls to convey the labels.

3 , The separated clutch makes the strain more balanced.It ensures accurate labeling.

4 , The advanced HMI,interface freely and the online helping system,easy to operate.

5 , The controlling system adopts SIMEMS PLC and famous panel,the interface can be operated in English to Chinese.

6 , It is convenient to adjust the labeling head,labeling speed is automatically synchronized with conveyor speed to ensure precisely labeling.

8 , During the labeling,no need to people to check the labeling for each bottle,you only need put the bottle on the conveyor,the labeling accuracy of first labeled bottle and the last labeled bottle is same.

9 , All machine before delivery,our engineers would debug the machine,inspect everything then delivery.

10 , Electrics are used international brand.

FAQ

1. Q: What label material does your machine use ?

A: Self-adhesive sticker.

2. Q: The machine is automatic or semi-auto?

A: We only produce the automatic machine .

3. Q: Which kinds of machine are suit for our products labeling requirement?

A:Pls supply us your products and label size (the photo of products with label on it is rather helpful), then I will suggest you the suitable machine for reference.

4. Q: The machine can connect with the product line or not ?

A: Machine can connect with production line or put on the production line or operation alon all ok as you need .

Product details
