Beverage Property Sticker Label Applicator , Automatic Sticker Labeling Machine

Detailed Product Description

Packaging Type:	Machine Put Sticker Label On Products	Material Of Equipment:	Aluminum And Stainless Steel
Label Width:	190mm	Condition:	New
Accuracy:	±0.8mm	OIperation Type:	Full-Automatic
Bottle Diameter/width:	30-110mm	Speed:	5000-10000B/H

Beverage Property Sticker Label Applicator , Automatic Sticker Labeling Machine

Application

1 , The machine applys to sigle side, double and facade labeling of all kinds ofsquare & flat bottles and round containers in pharmacy, food beverage,cosmetic ,detergent, oilindustry etc.

2 , Installed round bottle institution on it ,realize round bottle labeling ,plus one sensor ,can realize orientation labeling of the round bottles.The speed is around 2500B/H,max label high 168mm (accept custom).

3 , Using 82.6mm chain board width ,Suit for diameter / width 30-110mm bottles,flat bottle,round bottle,square bottle and some irregular bottles.

4 , Labeling head: new design,more stable,width 200mm,suit max label high 190mm,eight orienation adjustment.

5 , Machine can work with ribbon date printer and injek printer.

6 , When you have a lot of kinds of bottles,when labeling,only need to adjust machine.

7 , If youhaveoval bottle,we have new model design abeling machine ,whenyouapply oval bottle ,turn on synchronous chain correcting device,for oval bottle.if do other bottle labeling ,stop this labeling device,veryconvenient.

Technical Parameters

Production speed	45m/min
Labeling accuracy	±1mm
Label max width	190mm
Bottle diameter	30-100mm
Label inner diameter	76.2mm
Label outer diameter	Max330mm
Outline size	L2000×W700×1400mm
Air source	4-6KG 30L/MIn
Using power	220V 50HZ 1200W

Features

1 , This machine can automatically attach adhesive labels or stickers on the side surface of the product/ large curvature, circumference, and square surface, etc.

2 , Double sidescorrecting oriented chain, can make sure the bottlesin the middle and fix the shape on the conveyor to provide the labeling accuracy automatically.

3, Use PLC control system, touch screen, has standard sensor electronic control system, human control interface show prompted comments and complete function, operation function, easy to use and maintain.

4, Labeling smooth, not wrinkled, no bubbles, labeling accuracy, high efficiency, good stability.

5, Well-knowen motor drive is matched with the complete machine that ensures a stable and reliable label-feeding speed.

6, The sensor detect the product,transmit the signal to labeling control system;

7,  Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.

8, Beautiful appearance, beautifully designed,high efficiency machines,save labor cost

Tag: automatic labeler machine, bottle labeler machine
