Customized Water Bottle Labeling Machine , Automatic Bench Labeler Machine

Detailed Product Description

Bottle Separating Frequency Convertor:	TELTA	Size Of Machine:	2800(L)×1450(W)×1360(H)mm
Labeling Speed:	60-200pcs/min	Height Of Object:	30-280mm
Thickness Of Object:	20-200mm	Length Of Label:	25-300mm
Accuracy Of Labeling:	±1mm	Label Roller Outside Diameter:	320mm
Power Supply:	220v	Transform:	380v, 110v
The Brand Of Server Motor:	TELTA	Conveyor Motor:	H.Y（Taiwan）

Special customized water bottle bottle labeling machine, automatic bench labeler for double sides

Detailed product description:

Machine can be supplied with Optional Toughened (Tampered) Glass or Acrylic Safety Cabinet. Machines having required all basic features as a standard fitment to match the current MARKET needs and also saves cost and time.

Composed by main body, sending paper, receiving paper, bottle orientation etc parts.

All metal are made of 304 stainless steel with surface finishing and special treatment, which we can guarantee you very good quality.

Application:

Automatic bottle labeler double side sticker labeling Machine for pouches standing upis one of the most user friendly. The Machine incorporates latest sophisticated Micro Processor Control Label Dispensing system with user friendly Sensing system for Label and Product. The Machine is suitable for Labeling on Square Bottle, Jars or double pouches. It is capable of Labeling up to 250 Products per minute depending on products diameter and label size.

Techinical parameter:

No.	part	brand	quantity
1	PLC	MITSUBISHI(Japan)	1
2	Main converter	DANFOSS(Denmark)	1
3	Bottle separating frequency convertor	DELTA(Taiwan)	1
4	HMI	WEINVIEW(Taiwan)	1
5	Servo labeling motor	DELTA(Taiwan)	2
6	Servo labeling motor driver	DELTA(Taiwan)	2
7	Conveyor motor	H.Y(Taiwan)	1
8	Conveyor motor gearbox	H.Y(Taiwan)	1
9	Spoke motor	GPG(Taiwan)	1
10	Spoke motor gearbox	GPG(Taiwan)	1
11	Bottle separating motor	GPG(Taiwan)	2
12	Bottle separating motor gear box	GPG(Taiwan)	2
13	object detect magic eye	OMRON(Japan)	1
14	optical fiber	OMRON(Japan)	1
15	Powder	DELTA(Taiwan)	1
16	No label alarm magic eye	OMRON(Japan)	2
17	Label outing detect magic eye	LEUZE(Germany)	2

Services

Before Sales
1. Answer your any question on us within 24 hours.
2. Supply all information you required.
3. Machines video for reference
4. Welcome to visit factory

On Sales
1. Update production progress each week
2. Sending machines pictures on production
3. Machines testing running over 8 hours, and sending testing videos

After Sales
1. engineer arranged to install machines
2. Spare Parts provided
3. After sales hotline: 0086-021-34710825
